Type: Monofacial
Cell Type: Monocrystalline PERC half-cell
Number of cells:120
Maximum system voltage:1500V DC
Maximum fuse rated current:30A
Frame:Anodized aluminum alloy
Glass: 3.2mm Low-iron ultra-white tempered glass
Junction box: IP68, TUV&UL
Backsheet:white
Connectors: MC4 compatible
Cable:4.0mm² default 300mm,length can be customized
| Product Code | Lk-120M-590W590W | Lk-120M-595W595W | Lk-120M-600W600W | Lk-120M-605W605W | Lk-120M-610W610W |
|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 590 | 595 | 600 | 605 | 610 |
| Open Circuit Voltage(VOC/v) Voc/v | 41.1 | 41.3 | 41.5 | 41.7 | 41.9 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 34.0 | 34.2 | 34.4 | 34.6 | 34.6 |
| Short Circuit Current(Isc/A)Isc/A | 18.47 | 18.52 | 18.57 | 18.62 | 18.67 |
| Maximum Power Current(imp/A)imp/A | 17.35 | 17.40 | 17.44 | 17.49 | 17.55 |
| Dimension(mm)Dim.(mm) | 2172*1303*35 | ||||
| Weight(kg)Weight(kg) | 31 | ||||
| Power tolerance | ±3% tolerance | ||||
| α ISC | -0.042%/°C | ||||
| β Voc | -0.262%/°C | ||||
| γ Pmp | -0.362%/°C | ||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | ||||
| Remarks: | model is LK- 120M- () | ||||
