Type: Monofacial
Cell Type: Monocrystalline PERC half-cell
Number of cells:120
Maximum system voltage:1500V DC
Maximum fuse rated current:15A
Frame:Anodized aluminum alloy
Glass: 3.2mm Low-iron ultra-white tempered glass
Junction box: IP68, TUV&UL
Backsheet:white
Connectors: MC4 compatible
Cable:4.0mm², default 300mm,length can be customized
| Product Code | LK-120M-345W345W | LK-120M-355W355W | LK-120M-365W365W | LK-120M-375W375W | LK-120M-380W380W | LK-120M-385W385W |
|---|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 345 | 355 | 365 | 375 | 380 | 385 |
| Open Circuit Voltage(VOC/v) Voc/v | 40.0 | 40.4 | 40.8 | 41.3 | 41.6 | 41.7 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 33.0 | 33.7 | 34.1 | 34.5 | 34.8 | 34.9 |
| Short Circuit Current(Isc/A)Isc/A | 10.99 | 11.41 | 11.62 | 11.79 | 11.85 | 11.91 |
| Maximum Power Current(imp/A)imp/A | 10.46 | 10.53 | 10.69 | 10.86 | 10.92 | 11.03 |
| Dimension(mm)Dim.(mm) | 1755*1038*35 | |||||
| Weight(kg)Weight(kg) | 19.5 | |||||
| Power tolerance | ±3% tolerance | |||||
| α ISC | -0.05%/°C | |||||
| β Voc | -0.29%/°C | |||||
| γ Pmp | -0.4%/°C | |||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | |||||
| Remarks: | model is LK- 120M- () | |||||
