Type: Monofacial
Cell Type: Monocrystalline PERC half-cell
Number of cells:144
Maximum system voltage:1500V DC
Maximum fuse rated current:15A
Frame:Anodized aluminum alloy
Glass: 3.2mm Low-iron ultra-white tempered glass
Junction box: IP68, TUV&UL
Backsheet:white
Connectors: MC4 compatible
Cable:4.0mm² default 300mm,length can be customized
| Product Code | LK-144M-420W420W | LK-144M-430W430W | LK-144M-440W440W | LK-144M-445W445W | LK-144M-450W450W | LK-144M-455W455W |
|---|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 420 | 430 | 440 | 445 | 450 | 455 |
| Open Circuit Voltage(VOC/v) Voc/v | 48.27 | 48.65 | 49.05 | 49.28 | 49.51 | 49.60 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 40.59 | 40.72 | 41.08 | 41.28 | 41.47 | 41.52 |
| Short Circuit Current(Isc/A)Isc/A | 10.97 | 11.49 | 11.64 | 11.71 | 11.78 | 11.79 |
| Maximum Power Current(imp/A)imp/A | 10.35 | 10.56 | 10.71 | 10.78 | 10.85 | 10.96 |
| Dimension(mm)Dim.(mm) | 2094*1038*35 | |||||
| Weight(kg)Weight(kg) | 25 | |||||
| Power tolerance | ±3% tolerance | |||||
| α ISC | -0.05%/°C | |||||
| β Voc | -0.29%/°C | |||||
| γ Pmp | -0.4%/°C | |||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | |||||
| Remarks: | model is LK- 144M- () | |||||
