Type: Monofacial
Cell Type: Monocrystalline PERC half-cell
Number of cells:144
Maximum system voltage:1500V DC
Maximum fuse rated current:25A
Frame:Anodized aluminum alloy
Glass: 3.2mm Low-iron ultra-white tempered glass
Junction box: IP68, TUV&UL
Backsheet:white
Connectors: MC4 compatible
Cable:4.0mm² default 300mm,length can be customized
| Product Code | Lk-144M-540W540W | Lk-144M-545W545W | Lk-144M-550W550W | Lk-144M-555W555W |
|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 540 | 545 | 550 | 555 |
| Open Circuit Voltage(VOC/v) Voc/v | 49.60 | 49.75 | 49.90 | 49.91 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 41.64 | 41.80 | 41.96 | 41.98 |
| Short Circuit Current(Isc/A)Isc/A | 13.93 | 14.0 | 14.07 | 14.09 |
| Maximum Power Current(imp/A)imp/A | 12.97 | 13.04 | 13.11 | 13.22 |
| Dimension(mm)Dim.(mm) | 2278*1134*35 | |||
| Weight(kg)Weight(kg) | 28.6 | |||
| Power tolerance | ±3% tolerance | |||
| α ISC | -0.05%/°C | |||
| β Voc | -0.282%/°C | |||
| γ Pmp | -0.348%/°C | |||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | |||
| Remarks: | model is LK- 144M- () | |||
