Type: Monofacial
Cell Type: Monocrystalline PERC half-cell
Number of cells:120
Maximum system voltage:1500V DC
Maximum fuse rated current:25A
Frame:Anodized aluminum alloy
Glass: 3.2mm Low-iron ultra-white tempered glass
Junction box: IP68, TUV&UL
Backsheet:white
Connectors: MC4 compatible
Cable:4.0mm² default 300mm,length can be customized
| Product Code | Lk-120M-450W450W | Lk-120M-455W455W | Lk-120M-460W460W | Lk-120M-465W465W |
|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 450 | 455 | 460 | 465 |
| Open Circuit Voltage(VOC/v) Voc/v | 41.40 | 41.60 | 41.80 | 42.00 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 34.60 | 34.80 | 35.00 | 35.20 |
| Short Circuit Current(Isc/A)Isc/A | 13.68 | 13.73 | 13.78 | 13.83 |
| Maximum Power Current(imp/A)imp/A | 13.01 | 13.07 | 13.15 | 13.22 |
| Dimension(mm)Dim.(mm) | 1909*1134*35 | |||
| Weight(kg)Weight(kg) | 24 | |||
| Power tolerance | ±3% tolerance | |||
| α ISC | -0.05%/°C | |||
| β Voc | -0.282%/°C | |||
| γ Pmp | -0.348%/°C | |||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | |||
| Remarks: | model is LK- 120M- () | |||
