Cell Type: Monocrystalline
Number of cells:36
Module efficiency:≥19.1%
Maximum system voltage:1500V DC
Maximum fuse rated current:20A
Frame: Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP65/IP67
Connectors: MC4 compatible
| Product Code | LK-36M-250W250W | LK-36M-255W255W | LK-36M-260W260W | LK-36M-265W265W | LK-36M-270W270W | LK-36M-275W275W |
|---|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 250 | 255 | 260 | 265 | 270 | 275 |
| Open Circuit Voltage(VOC/v) Voc/v | 24.35 | 24.44 | 24.55 | 24.62 | 24.70 | 24.77 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 20.29 | 20.41 | 20.55 | 20.74 | 20.81 | 20.88 |
| Short Circuit Current(Isc/A)Isc/A | 13.11 | 13.31 | 13.50 | 13.70 | 13.91 | 14.13 |
| Maximum Power Current(imp/A)imp/A | 12.32 | 12.49 | 12.65 | 12.78 | 12.97 | 13.17 |
| Dimension(mm)Dim.(mm) | 1700*770*35 | |||||
| Weight(kg)Weight(kg) | 12 | |||||
| Power Tolerance | ±3% tolerance | |||||
| α ISC | -0.05%/°C | |||||
| β Voc | -0.29%/°C | |||||
| γ Pmp | -0.4%/°C | |||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | |||||
| Remarks: | model is LK- 36M- () | |||||
