Cell Type: Monocrystalline
Number of cells:72
Module efficiency:≥17.7%
Maximum system voltage:1500V DC
Maximum fuse rated current:20A
Frame: Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP65/IP67
Connectors: MC4 compatible
| Product Code | LK-72M-350W350W | LK-72M-370W370W | LK-72M-390W390W | LK-72M-400W400W | LK-72M-410W410W | LK-72M-420W420W |
|---|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 350 | 370 | 390 | 400 | 410 | 420 |
| Open Circuit Voltage(VOC/v) Voc/v | 46.1 | 47.3 | 48.2 | 48.5 | 48.8 | 48.9 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 37.3 | 38.3 | 39.2 | 39.5 | 39.8 | 39.9 |
| Short Circuit Current(Isc/A)Isc/A | 9.99 | 10.03 | 10.37 | 10.51 | 10.63 | 10.87 |
| Maximum Power Current(imp/A)imp/A | 9.38 | 9.66 | 9.95 | 10.13 | 10.30 | 10.53 |
| Dimension(mm)Dim.(mm) | 1980*996*35 | |||||
| Weight(kg)Weight(kg) | 20.5 | |||||
| Power tolerance | ±3% tolerance | |||||
| α ISC | -0.05%/°C | |||||
| β Voc | -0.29%/°C | |||||
| γ Pmp | -0.4%/°C | |||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | |||||
| Remarks: | model is LK- 72M- () | |||||
