Cell Type: Monocrystalline
Number of cells:48
Module efficiency:≥17.5%
Maximum system voltage:1000V DC
Maximum fuse rated current:15A
Frame: Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP65/IP67
Connectors: MC4 compatible
| Product Code | LK-48M-230W230W | LK-48M-240W240W | LK-48M-250W250W | LK-48M-260W260W | LK-48M-270W270W |
|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 230 | 240 | 250 | 260 | 270 |
| Open Circuit Voltage(VOC/v) Voc/v | 30.9 | 31.5 | 31.8 | 32.1 | 32.4 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 24.9 | 25.5 | 25.8 | 26.2 | 26.5 |
| Short Circuit Current(Isc/A)Isc/A | 9.67 | 9.77 | 10.01 | 10.25 | 10.55 |
| Maximum Power Current(imp/A)imp/A | 9.24 | 9.42 | 9.69 | 9.93 | 10.19 |
| Dimension(mm)Dim.(mm) | 1324*992*35 | ||||
| Weight(kg)Weight(kg) | 15 | ||||
| Power Tolerance | ±3% tolerance | ||||
| α ISC | -0.05%/°C | ||||
| β Voc | -0.29%/°C | ||||
| γ Pmp | -0.4%/°C | ||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | ||||
| Remarks: | model is LK- 48M- () | ||||
