Cell Type: Monocrystalline
Number of cells:36
Module efficiency:≥18.1%
Maximum system voltage:1000V DC
Maximum fuse rated current:20A
Frame: Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP65/IP67
Connectors: MC4 compatible
| Product Code | LK-36M-200W200W | LK-36M-210W210W | LK-36M-215W215W | LK-36M-220W220W | LK-36M-225W225W |
|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 200 | 210 | 215 | 220 | 225 |
| Open Circuit Voltage(VOC/v) Voc/v | 23.0 | 23.4 | 23.8 | 24.1 | 24.5 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 19.8 | 20.2 | 20.5 | 20.9 | 21.2 |
| Short Circuit Current(Isc/A)Isc/A | 11.13 | 11.46 | 11.54 | 11.62 | 11.69 |
| Maximum Power Current(imp/A)imp/A | 10.10 | 10.42 | 10.48 | 10.54 | 10.59 |
| Dimension(mm)Dim.(mm) | 1560*710*35 | ||||
| Weight(kg)Weight(kg) | 12 | ||||
| Power Tolerance | ±3% tolerance | ||||
| α ISC | -0.05%/°C | ||||
| β Voc | -0.29%/°C | ||||
| γ Pmp | -0.4%/°C | ||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | ||||
| Remarks: | model is LK- 36M- () | ||||
