Cell Type: polycrystalline
Number of cells:36
Module efficiency:≥15.1%
Maximum system voltage:1000V DC
Maximum fuse rated current:15A
Frame:Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP65/IP67
Connectors: MC4 compatible
| Product Code | LK-36M-150W150W | LK-36M-155W155W | LK-36M-160W160W | LK-36M-165W165W | LK-36M-170W170W | ||
|---|---|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 150 | 155 | 160 | 165 | 170 | ||
| Open Circuit Voltage(VOC/v) Voc/v | 21.2 | 22.4 | 22.6 | 22.8 | 23.2 | ||
| Maximum Power Voltage(Vmp/V) Vmp/V | 18.0 | 18.2 | 18.4 | 18.7 | 19.1 | ||
| Short Circuit Current(Isc/A)Isc/A | 9.01 | 9.17 | 9.32 | 9.46 | 9.52 | ||
| Maximum Power Current(imp/A)imp/A | 8.34 | 8.52 | 8.70 | 8.83 | 8.91 | ||
| Dimension(mm)Dim.(mm) | 1480*670*35 | ||||||
| Weight(kg)Weight(kg) | 11 | ||||||
| Power tolerance | ±3% tolerance | ||||||
| α ISC | -0.05%/°C | ||||||
| β Voc | -0.29%/°C | ||||||
| γ Pmp | -0.4%/°C | ||||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | ||||||
| Remarks: | model is LK- 36M- () | ||||||
