Type: Monofacial
Cell Type: Monocrystalline half-cell
Number of cells:64
Maximum system voltage:1500V DC
Maximum fuse rated current:20A
Frame: Anodized aluminum alloy
Glass: 3.2mm Low-iron ultra-white tempered glass
Junction box: IP68, TUV&UL
Backsheet: white
Connectors: MC4 compatible
Cable:4.0mm² default 300mm, length can be customized
| Product Code | LK-64M-310W310W | LK-64M-315W315W | LK-64M-320W320W | LK-64M-325W325W | LK-64M-330W330W |
|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 310 | 315 | 320 | 325 | 330 |
| Open Circuit Voltage(VOC/v) Voc/v | 43.10 | 43.30 | 43.50 | 43.70 | 43.90 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 34.75 | 34.90 | 35.05 | 35.20 | 35.35 |
| Short Circuit Current(Isc/A)Isc/A | 9.40 | 9.45 | 9.49 | 9.60 | 9.64 |
| Maximum Power Current(imp/A)imp/A | 8.92 | 9.02 | 9.13 | 9.23 | 9.33 |
| Dimension(mm)Dim.(mm) | 1740*880*35 | ||||
| Weight(kg)Weight(kg) | 15.5 | ||||
| Power Tolerance | ±3% tolerance | ||||
| α ISC | -0.05%/°C | ||||
| β Voc | -0.29%/°C | ||||
| γ Pmp | -0.4%/°C | ||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | ||||
| Remarks: | model is LK- 64M- () | ||||
