Type: Monofacial
Cell Type: Monocrystalline half-cell
Number of cells:48
Maximum system voltage:1500V DC
Maximum fuse rated current:20A
Frame:Anodized aluminum alloy
Glass: 3.2mm Low-iron ultra-white tempered glass
Junction box: IP68, TUV&UL
Backsheet:white
Connectors: MC4 compatible
Cable:4.0mm² default 300mm,length can be customized
| Product Code | LK-48M-230W230W | LK-48M-235W235W | LK-48M-240W240W | LK-48M-245W245W | LK-48M-250W250W |
|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 230 | 235 | 240 | 245 | 250 |
| Open Circuit Voltage(VOC/v) Voc/v | 32.3 | 32.5 | 32.7 | 32.9 | 33.1 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 26.1 | 26.3 | 26.5 | 26.5 | 26.7 |
| Short Circuit Current(Isc/A)Isc/A | 9.31 | 9.39 | 9.47 | 9.55 | 9.68 |
| Maximum Power Current(imp/A)imp/A | 8.81 | 8.94 | 9.06 | 9.25 | 9.36 |
| Dimension(mm)Dim.(mm) | 1310*880*35 | ||||
| Weight(kg)Weight(kg) | 11.5 | ||||
| Power tolerance | ±3% tolerance | ||||
| α ISC | -0.05%/°C | ||||
| β Voc | -0.29%/°C | ||||
| γ Pmp | -0.4%/°C | ||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | ||||
| Remarks: | model is LK- 48M- () | ||||
